| Descriptions | Specifications |
|---|---|
| Passage width | 550 mm |
| Throughput Rate | 40P/M |
| Power Supply | 220~240 V(AC) |
| Operational Voltage | 24 V(DC) |
| Max Power Consumption | 32 W |
| Frequency | 50~60 Hz |
| Ingress Protection | 66 IP |
| Working Temperature Minus | 25 to +70 |
| 70Electro-Magnetic Drive | DC |
| Dimension Excluding Bars | 480x280x980 mm |
| Net Weight Including Bars | 44 KG |
| MTBF Operations | 200000 |
| Frame/ Cover Stainless Steel | SS304 |
| Display | Red/ Green LEDVisual |
| Visual Indicator | Optional |
