| Descriptions | Specifications |
|---|---|
| Passageway: | 650 mm |
| Dimension: | 1630*1500*2310 mm |
| Power Supply | 220~240 V(AC) |
| Control Circuit | 24 V(DC) |
| Power Consumption | 30 W |
| Frequency | 50~60 Hz |
| Protection level | IP 44 |
| Operating Temperature Range | -25 to +70 oC |
| Electro-Magnetic Drive | DC |
| Humidity | 95% |
| Net Weight | 210 KG |
| Hydraulic Damper | Adjustable |
| Solenoid | 24v DC 100% |
| Thought | Person |
| Signal Output | 12 v pulse |
