| S.No. | Features |
|---|---|
| 1 | Keypad / single button interface. |
| 2 | Electromechanical AC motor with built-in control unit. |
| 3 | Alarm lamp, photo beam & safety beam interface. |
| 4 | User can select auto-close function. |
| 5 | Soft start and slow stop. (Smart version) |
| 6 | Auto-reverse function when hitting obstacle during closing. (Smart version) |
| 7 | Manual key release design for emergency purposes. |
| Descriptions | Specifications | 1500 AC | 1500 ACL |
|---|---|---|
| Power Supply | AC220V/50Hz; AC110V/60Hz | |
| Maximum Gate Weight | 1500KG | |
| Motor Power | 550W | |
| Output Torque | 32N.m | |
| Output Shaft Height | 50mm | |
| Limit Switch | Magnetic limit switch or Spring limit switch | |
| Gate Moving Speed | 13m/min | |
| Remote Control Range | ≥30 m | |
| Recording of Up Remotes | 25 | |
| Frequency | 433.92MHz | |
| Work Duty | S2 15min | |
| Noise | ≤58dB | |
| Working Temperature | -20℃～50℃ | |
| Driving Mode | Gear | Chainn |
| Package Weight | 14.00KG | 23.50KG |
