| S.No. | Features |
|---|---|
| 1 | Image Archiving |
| 2 | Multi-language Support. |
| 3 | Dual-energy Material Discrimination |
| 4 | Assist to Detect Drug and Explosive Powder |
| 5 | Ideal Method of Inspecting Oversized and Bulky Freight |
| 6 | Ease of Handling Heavy Goods via Low Conveyor Belt |
| 7 | Ergonomically Designed Operating Console Features User-friendly |
| 8 | GPU-accelerated Image Processing |
| Descriptions | Specifications |
|---|---|
| Tunnel Size | 500(W) ×300 (H) m |
| Conveyor Max. Load | 200kg |
| Conveyor Speed | 0.20m/s |
| Resolution | 0.1mm metal wire |
| Penetration | 10mm steel |
| Film Safety | Guaranteed up to high speed film ISO 1600 |
| X-ray Leakage | less than 1μSv/h (at a distance of 5 cm from extern al housing) |
| X-ray Voltage | 140KV |
| Cooling/Duty cycle | Oil cooling/100% |
| Image System X-ray Sensor | L-shaped photodiodes array |
| Image Presentation | B/W, pseudo color, multi-energy |
| Image Processing: edge | enhancement, inorganic stripping, organic stripping, negative, |
| Storage Image | Storage 20000 pictures real time |
| Zone & Zoom | 9 image region, 2-, 4-, 8-times enlargement |
| Image Grey Level | 4096 |
| Image Max Resolution | 1280 ×1024 pixel |
| Image Processing | High resolution color double liquid crystal display |
| Monitor | High resolution color double liquid crystal display |
| Additional Features | Fading-in of date/time, luggage counter, user ID- number display of operating mode, power-on self- diagnosis, network interface |
| Data Operating Temperature/ Humidity | 0oC ~ 45oC/20% ~ 95 %( non-condensing) -10oC ~ 45oC/20% ~ 95 %( selectable) |
| Storage Temperature/ Humidity | 20oC ~ 60oC/20% ~ 95 %( non-condensing) |
| Power/Power Consumption | 220VAC (+10% ~ -15%) 50+3Hz/1.4KAV |
