| S.No. | Features |
|---|---|
| 1 | Keypad / single button interface. |
| 2 | Electromechanical AC motor with built-in control unit. |
| 3 | Alarm lamp, photo beam & safety beam interface. |
| 4 | User can select auto-close function. |
| 5 | Soft start and slow stop. (Smart version) |
| 6 | Auto-reverse function when hitting obstacle during closing. (Smart version) |
| 7 | Manual key release design for emergency purposes. |
| Descriptions | Specifications |
|---|---|
| Power Supply | AC380V |
| Maximum Gate Weight | 2000KG |
| Motor Power | 750W |
| Output Torque | 40N.m |
| Output Shaft Height | 56mm |
| Limit Switch | Magnetic limit switch or Spring limit switch |
| Gate Moving Speed | 13m/min |
| Remote Control Range | ≥30 m |
| Recording of Up Remotes | 25 |
| Frequency | 433.92MHz |
| Work Duty | S2 15min |
| Noise | ≤60dB |
| Working Temperature | -20℃～50℃ |
| Backup Battery | ------ |
| Driving Mode | Gear |
| Package Weight | 17.00KG |
